Application

Series XVF vacuum-type transformer oil regeneration device use of the special chemicals for purifying and regenerating the unqualified transformer oil, switch oil, turbine oil, hydraulic oil etc. It adopts the vacuum (negative pressure) adsorbtion way to regenerate the old oil, it is more effective than postive regeneration way, one regeneration pass can recovery 99% of oil performance. We know the Industrial oils are easy to oxidize, carbonize and rancidity after a period of using, so oil color will became dark yellow and dark red with bad smell; Oil lost the using performance. The traditional filtration machine only remove the particles, but it can't remove the phospholipids, saponin carbon, oxidation materials, acid etc. XVF Vacuum oil regeneration device combine the vacuum filtration and Physical adsorption technology, which can remove the harmful materials from oil, like the phospholipids, saponin, oxidation, carbon, acid etc. Recovering the oil color and oil performance, the treated oil is good color and performance.

Features:

1.Using vacuum regeneration way and Physical adsorption technology, no damaged for the oil. High regeneration effection.

2.Effectively remove the harmful pigments from oil, oil color and smell are good.

 3.Smart design, Automatically suction and pumping the oil, easy operation.

 4.Widely using, regenerate lube oil, hydraulic oil, transformer oil, turbine oil

 5.Adopts the quick-open design, easy to change the chemicals.

The regenerated Transformer oil Indexes:

Oil Color: Light and Transparent

Dielectric strength: KV ≥ 55

Flash point(close cup) ℃:≥135

Water-solubility: PH ≥5.4

Dielectric-factor loss: tgδ (90℃) ≤0.005

Acid value: mgKOH/g ≤ 0.01
